The VeCODER ULTRA 4K H.264/H.265 is our top multichannel UHD encoder. Each 4K channel can run HEVC for roughly half the bitrate, so several Ultra-HD channels share one network gracefully. Manage every channel from a single web interface in one 1RU chassis.
Multichannel 4K IPTV Encoder · HEVC
Flagship Multichannel 4K, Made Practical
2 to 8 independent 4K channels with selectable HEVC H.265 — the efficiency that makes multichannel Ultra-HD fit on networks H.264 alone could not handle.
Capabilities
HEVC Is What Makes Multichannel 4K Work
Halve the bitrate per 4K channel and suddenly several Ultra-HD streams coexist on a network you already own.
- 2 / 4 / 6 / 8 HDMI inputs — each an independent 4K channel
- Selectable HEVC H.265 or H.264 per channel · per-channel multi-stream output
- M3U8/HLS, RTMP(S), RTSP, HTTP, UDP/RTP, SRT · unicast & multicast
- Built-in gigabit streaming server — no external server, no per-seat fees
- Unified web management · 24/7 redundant-grade cooling
Reaches Everything
Premium UHD, Sensible Bandwidth
Deliver multiple 4K channels to premium screens and lighter renditions everywhere else — efficiently, from one rack unit.
Land 4K on TVs with our VePLAYER 4K decoders, or distribute UHD over existing coax with the INFINIUM 4K headend. Don't need HEVC? The VeCODER ULTRA 4K H.264 is the simpler option.
Features
The Flagship Multichannel 4K Headend
Maximum UHD density on real-world networks.
True 4K Channels
Each input encodes genuine 3840×2160 Ultra-HD.
HEVC Efficiency
Roughly half the bitrate per 4K channel vs H.264.
Per-Channel Codec
HEVC or H.264 selectable independently per channel.
Unicast + Multicast
IGMP multicast to unlimited devices across the building.
One Interface
Configure and monitor every 4K channel from a single web UI.
Made in USA
Built for 24/7 duty. 5-year warranty, free lifetime support.
Specifications
VeCODER ULTRA 4K H.264/H.265 Specifications
| Encoder Type | Multichannel 4K HDMI IPTV encoder · rack streaming server |
| Channels | 2 / 4 / 6 / 8 independent 4K HDMI inputs |
| Max Resolution | 3840×2160 (4K) per channel |
| Video Compression | HEVC (H.265) & H.264 (AVC), selectable per channel · MJPEG |
| Streams | Multiple independent streams per channel, each its own format/protocol |
| Audio | HDMI embedded per channel · AAC / MP3 / MP2 / AC3 / PCM |
| Streaming Protocols | SRT, RTMP(S), M3U8/HLS, HTTP, RTSP, RTP, FLV, ONVIF, UDP/RTP uni/multicast |
| Built-In Server | Hardware secure server, gigabit connections |
| Management | Unified web interface for all channels |
| Form Factor | 1RU rack chassis · redundant-grade cooling |
| SKU | VECODER-4K-HEVC (2/4/6/8) |
| Warranty | 5-Year Manufacturer Warranty + free lifetime support |
| Origin | Designed & Built in USA |
FAQ
VeCODER ULTRA 4K H.264/H.265 — FAQ
Why is HEVC important for multichannel 4K?
4K is bandwidth-heavy. HEVC roughly halves the bitrate per channel, which is often the difference between fitting several 4K channels on your network or not. This is the model to choose for dense UHD deployments.
Can each 4K channel use a different codec?
Yes — HEVC or H.264 is selectable per channel, so you can tune each channel for its destination devices and the available bandwidth.
How many 4K channels are available?
Choose 2, 4, 6, or 8 independent 4K channels in one 1RU chassis.
Is an external server required?
No. The built-in gigabit hardware server streams directly on your LAN or the internet with no monthly fees.
How do I receive the 4K channels?
Use 4K IP set-top boxes, smart-TV apps, or our VePLAYER 4K decoders. For coax distribution, pair with the INFINIUM 4K headend.
What bandwidth per HEVC 4K channel?
Typically 8–20 Mbps depending on content — roughly half of the equivalent H.264 channel.
Do you have an HD version?
Yes — the VeCODER ULTRA HD H.264/H.265 scales to 16 HD channels per chassis.
Build Your System
Build Your Flagship 4K Headend
Add 4K decoders, choose your channel count and codec, or distribute over coax with INFINIUM.
VePLAYER 4K IP Decoder
Decode any 4K channel back to HDMI for Ultra-HD TVs and video walls.
$549.00$495.00You save $54.00
VeCODER ULTRA 4K H.264
The simpler option when you don't need HEVC.
From
$3,590.00
VeCODER ULTRA HD HEVC
Need HD channels? Scale to 16 HEVC HD channels.
From
$3,590.00
INFINIUM 4K Headend
Distribute 4K over IP and existing coax with hot-swappable cards.
$1,195.00$995.00You save $200.00
Run Multichannel 4K Efficiently
$3,590.00
Free shipping over $500 · 5-year warranty · Free unlimited tech support · Made in USA
